Galvanized angled union 095 FF

Thread pipe fitting from malleable cast iron, kind – union elbow with flat seat with inner x inner tubular connection threads, galvanized design. Inner threads Rc is conical for sealing of joints on the threads according of norm ISO 7-1. Produced according of norm EN 10242, mark UA1.

Attention: union should use like built-up of complex only, because individual parts of the union with different production marks or individual parts of different types and same production marks can’t be compatible!

Using:

Intended for distribution of water, air, nonabrassive and nonaggressive fluid to allowed press 25 bar and temperature from -20 until 120°C, with necessity of prevention for freezing of media.
